Mastering Arduino Pulse Width Modulation: Build a Silent 20kHz Motor Controller

The Hardware Reality of Arduino Pulse Width Modulation

Arduino pulse width modulation (PWM) is not true analog output; it is a digital square wave where the ratio of ON time to OFF time (duty cycle) simulates an average voltage. When you call the standard analogWrite() function on an ATmega328P-based board (like the Uno or Nano), the microcontroller toggles the pin HIGH and LOW at a fixed frequency. For most pins, this default frequency is roughly 490Hz. Pins 5 and 6 run at 980Hz.

While 490Hz is fine for dimming an LED, it falls squarely in the audible frequency range. When you drive a brushed DC motor or a high-power inductor at 490Hz, the magnetic fields cause physical vibration in the coils and stator—a phenomenon known as magnetostriction. The result is an annoying, high-pitched mechanical whine. To eliminate this, we push the PWM frequency above the human hearing threshold (typically 20kHz) by directly manipulating the hardware timers.

ATmega328P Hardware Timer & PWM Architecture

Understanding which timer controls which pin is the most common stumbling block in embedded PWM design. The table below maps the physical pins to their underlying hardware timers on the ATmega328P (Uno/Nano).

Parts List & Pin Mapping

This build targets the Arduino Nano v3 (ATmega328P, 16MHz, 5V logic). We are using a dedicated H-bridge motor driver rather than a single MOSFET to allow for bidirectional control and built-in dead-time protection, which prevents shoot-through current that can fry your silicon.

Required Components

• Microcontroller: Arduino Nano v3 (ATmega328P variant, not the newer Nano Every or Nano 33 IoT for this specific timer code).
• Motor Driver: TB6612FNG Dual Motor Driver Carrier (Handles 1.2A continuous, 3.2A peak per channel. Far superior to the ancient L298N which drops ~2V across its bipolar transistors).
• Motor: 12V Brushed DC Motor (e.g., RS-550 or similar 1-3A draw).
• Input: 10kΩ Linear Taper (B10K) Potentiometer.
• Power Supply: 12V DC bench supply or battery pack (capable of ≥3A).

Pin Mapping Table

Wiring & Compilable 20kHz Code

Before uploading, wire the potentiometer wiper to A0, with the outer legs to 5V and GND. Connect the TB6612FNG VM to your 12V supply, and ensure the 12V supply GND is tied to the Arduino GND. Without a common ground, the PWM logic signals will float, causing erratic motor behavior.

1. Connect Nano D9 to TB6612FNG PWMA.
2. Connect Nano D7 to AIN1, and D8 to AIN2.
3. Tie TB6612FNG STBY to 5V (or a digital pin if you want software standby).
4. Connect Motor leads to A01 and A02.

The code below uses the TimerOne library to reconfigure Timer1 for a 50-microsecond period (20kHz). Note that TimerOne uses a 10-bit resolution (0-1023) for duty cycle, unlike the 8-bit (0-255) resolution of standard analogWrite().

#include <TimerOne.h>

// --- PIN DEFINITIONS ---
const int PIN_PWM = 9;      // Must be Timer1 pin (9 or 10 on Uno/Nano)
const int PIN_AIN1 = 7;     // Direction logic 1
const int PIN_AIN2 = 8;     // Direction logic 2
const int PIN_POT = A0;     // Potentiometer analog input

// --- CONSTANTS ---
const int PWM_PERIOD_US = 50; // 50us = 20,000Hz (20kHz)
const int DEADZONE_LOW = 40;  // Ignore pot noise at the bottom
const int DEADZONE_HIGH = 980; // Max out before physical end of pot travel

void setup() {
  pinMode(PIN_AIN1, OUTPUT);
  pinMode(PIN_AIN2, OUTPUT);
  pinMode(PIN_POT, INPUT);

  // Set initial direction (Forward)
  digitalWrite(PIN_AIN1, HIGH);
  digitalWrite(PIN_AIN2, LOW);

  // Initialize Timer1 for 20kHz PWM
  Timer1.initialize(PWM_PERIOD_US);
  Timer1.pwm(PIN_PWM, 0); // Start at 0% duty cycle

  Serial.begin(115200);
  Serial.println("20kHz Silent PWM Motor Controller Initialized.");
}

void loop() {
  int rawPot = analogRead(PIN_POT);

  // Error handling / Noise filtering: Implement a deadzone
  int mappedPWM = 0;

  if (rawPot < DEADZONE_LOW) {
    mappedPWM = 0; // Hard stop to prevent low-voltage twitching
  } else if (rawPot > DEADZONE_HIGH) {
    mappedPWM = 1023; // Full speed
  } else {
    // Map the usable range to TimerOne's 10-bit resolution (0-1023)
    mappedPWM = map(rawPot, DEADZONE_LOW, DEADZONE_HIGH, 0, 1023);
  }

  // Apply PWM via TimerOne
  Timer1.pwm(PIN_PWM, mappedPWM);

  // Debug output (throttled to avoid serial buffer flooding)
  static unsigned long lastPrint = 0;
  if (millis() - lastPrint > 250) {
    Serial.print("Pot Raw: ");
    Serial.print(rawPot);
    Serial.print(" | PWM Duty (10-bit): ");
    Serial.println(mappedPWM);
    lastPrint = millis();
  }

  delay(10); // Small delay for ADC settling
}

Debugging PWM Failures & Exact Error Strings

When working with Arduino pulse width modulation across different ecosystems, you will inevitably hit compiler errors or silent runtime failures. Below are the most common exact error strings and their ranked causes.

The ESP32 Migration Error

If you copy standard AVR Arduino PWM code to an ESP32 running Arduino Core v3.x, compilation will fail. In 2024, Espressif officially deprecated and removed analogWrite() from the ESP32 Arduino Core to enforce the use of the LED Control (LEDC) peripheral API.

error: 'analogWrite' was not declared in this scope

Ranked Causes & Fixes:

1. Using ESP32 Core 3.x: The function no longer exists. Fix: Replace analogWrite(pin, val) with ledcAttach(pin, freq, resolution) in setup, and ledcWrite(pin, val) in the loop.
2. Missing Include: If using a wrapper library that attempts to alias it, ensure you have the correct board manager URL and core version installed.

The TimerOne Architecture Error

If you attempt to compile the 20kHz code above on an Arduino Mega 2560 or an ARM-based board (like the Zero or Nano 33 IoT), the compiler will halt.

#error "TimerOne library only supports ATmega168/328"

Ranked Causes & Fixes:

1. Wrong Board Selected: You are using a non-AVR board. Fix: Use the PWM.h library for ARM boards, or the ESP32_AnalogWrite wrapper for ESP32.
2. Arduino Mega Pin Mapping: The Mega uses different pins for Timer1 (Pins 11 and 12). If you must use a Mega, switch to the TimerThree or TimerFour libraries and update your physical wiring to match the Mega's timer pinout.

The First Three Things to Check When PWM Fails

If your code compiles but the motor stutters, whines, or refuses to spin, run through this diagnostic sequence before rewriting your code.

How to Extend or Simplify the Build

To Simplify: If you are driving a small 5V fan or an LED strip where audible whine is not an issue, strip out the TimerOne library entirely. Replace Timer1.pwm(PIN_PWM, mappedPWM) with analogWrite(PIN_PWM, mappedPWM / 4). (Dividing by 4 scales the 10-bit 0-1023 value down to the 8-bit 0-255 range expected by analogWrite). This removes the external dependency and frees up Timer1 for other uses.

To Extend: Open-loop PWM only guesses the motor speed based on voltage. Under load, the motor will slow down. To build a professional-grade controller, add a quadrature rotary encoder to the motor shaft and wire it to the Arduino's hardware interrupt pins (D2 and D3). Implement the PID_v1 library to create a closed-loop feedback system that dynamically adjusts the PWM duty cycle to maintain a constant RPM regardless of mechanical load.

References & Further Reading

• Arduino Official Reference: analogWrite() - Details on default frequencies and 8-bit resolution limits.
• Pololu TB6612FNG Datasheet & Carrier Board - Essential reading for understanding H-bridge dead-time and logic voltage requirements.
• Espressif Arduino Core 3.0 Migration Guide - Official documentation on the removal of analogWrite and transition to LEDC APIs.
