Build an ESP32 Breaker Panel Clearance Code Monitor (NEC 110.26)

The NEC 110.26 breaker panel clearance code mandates a strict 36-inch deep, 30-inch wide, and 6.5-foot high clear working space in front of your electrical panel. In cluttered basements or garages, it is easy to accidentally stack boxes or build shelving that violates this boundary, creating a severe safety hazard for anyone troubleshooting a tripped breaker. To automate compliance monitoring, you can build an ESP32-based ultrasonic distance sensor that triggers a local OLED alert the moment an object breaches a 38-inch threshold (allowing a 2-inch buffer for sensor cone spread). This guide provides the exact hardware, pinout, and C++ code to build this monitor, while breaking down the specific NEC rules you need to know to pass an inspection.

The NEC 110.26 Standard & Project Overview

Before we wire the sensor, you need to understand the exact dimensions the National Electrical Code (NEC) requires for working space. According to NEC 110.26(A), the clearance is defined in three dimensions:

• Depth: For standard residential 120/240V systems (0-150V to ground), Table 110.26(A)(1) requires a minimum depth of 36 inches (3 feet). This is measured from the exposed live parts of the panel (or the front of the panel if the cover is on) straight out into the room.
• Width: NEC 110.26(A)(2) dictates the width must be at least 30 inches, or the width of the equipment itself, whichever is greater. This space must be centered on the panel.
• Height: NEC 110.26(A)(3) requires the space to be clear from the floor up to 6.5 feet (or the height of the equipment if it is taller).

Hardware Spec Sheet & Pin Mapping

This build targets the ESP32-WROOM-32 DevKit v1 (30-pin variant). We are using the HC-SR04 ultrasonic sensor because it offers reliable 2cm to 400cm ranging, which perfectly covers our 36-inch (91.4cm) threshold. However, the HC-SR04 Echo pin outputs 5V logic, which will fry the 3.3V-tolerant GPIOs on the ESP32. A voltage divider is mandatory.

ESP32 Pin Mapping Table

Step-by-Step Assembly & Compilable Code

1. Build the Voltage Divider: Solder the 1kΩ resistor to the HC-SR04 Echo pin. Connect the other end of the 1kΩ resistor to GPIO 27. Solder the 2kΩ resistor between GPIO 27 and GND. Verify with a multimeter that the resistance ratio is correct before applying power.
2. Mount the Sensor: Secure the HC-SR04 to a wooden stud or drywall anchor exactly 38 inches away from the front face of the breaker panel. Ensure the sensor is at least 4 feet off the ground to avoid detecting baseboards or floor clutter.
3. Wire the I2C OLED: Connect the SSD1306 display to GPIO 21 (SDA) and GPIO 22 (SCL). Ensure you are using the 3.3V pin for power.
4. Flash the Firmware: Install the Adafruit_SSD1306 and Adafruit_GFX libraries via the Arduino IDE Library Manager. Select "ESP32 Dev Module" as your board, copy the code below, and flash.

#include <Wire.h>
#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>

// --- PIN DEFINITIONS ---
#define TRIG_PIN 25
#define ECHO_PIN 27
#define SCREEN_WIDTH 128
#define SCREEN_HEIGHT 64
#define OLED_RESET -1
#define SCREEN_ADDRESS 0x3C

// --- THRESHOLDS ---
// NEC 110.26 requires 36" (91.44cm). We set warning at 38" (96.52cm).
#define CLEARANCE_THRESHOLD_CM 96.5
#define TIMEOUT_US 30000 // 30ms timeout for pulseIn

Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET);

void setup() {
  Serial.begin(115200);
  pinMode(TRIG_PIN, OUTPUT);
  pinMode(ECHO_PIN, INPUT);
  digitalWrite(TRIG_PIN, LOW);

  if(!display.begin(SSD1306_SWITCHCAPVCC, SCREEN_ADDRESS)) {
    Serial.println(F("[FAULT] SSD1306 allocation failed"));
    for(;;); // Halt if display fails
  }

  display.clearDisplay();
  display.setTextSize(1);
  display.setTextColor(SSD1306_WHITE);
  display.setCursor(0,0);
  display.println("NEC 110.26 Monitor");
  display.println("Initializing...");
  display.display();
  delay(1000);
}

void loop() {
  // Trigger ultrasonic ping
  digitalWrite(TRIG_PIN, LOW);
  delayMicroseconds(2);
  digitalWrite(TRIG_PIN, HIGH);
  delayMicroseconds(10);
  digitalWrite(TRIG_PIN, LOW);

  // Read echo with strict timeout to prevent hanging
  unsigned long duration = pulseIn(ECHO_PIN, HIGH, TIMEOUT_US);

  display.clearDisplay();
  display.setCursor(0,0);
  display.println("Panel Clearance Mon");
  display.drawLine(0, 10, 128, 10, SSD1306_WHITE);

  if (duration == 0) {
    // Error Handling: Timeout or stuck pin
    Serial.println("[FAULT] ECHO_TIMEOUT: Pin 27 stuck HIGH > 30ms");
    display.setCursor(0, 20);
    display.setTextSize(1);
    display.println("ERROR: Sensor Timeout");
    display.println("Check voltage divider");
    display.println("and 5V rail stability.");
  } else {
    float distance_cm = (duration * 0.0343) / 2.0;
    float distance_in = distance_cm / 2.54;

    display.setCursor(0, 20);
    display.setTextSize(2);
    display.print(distance_in, 1);
    display.println(" in");

    display.setTextSize(1);
    display.setCursor(0, 50);
    if (distance_cm < CLEARANCE_THRESHOLD_CM) {
      display.println("WARNING: CODE VIOLATION");
      Serial.printf("[ALERT] Clearance violated: %.2f inches (Limit: 36 in)\n", distance_in);
    } else {
      display.println("STATUS: NEC Compliant");
    }
  }
  display.display();
  delay(500); // 2Hz polling rate
}

Debugging: First Three Checks & Timeout Errors

If your serial monitor outputs the exact string [FAULT] ECHO_TIMEOUT: Pin 27 stuck HIGH > 30ms, the ESP32's pulseIn() function hit the 30-millisecond timeout without seeing the Echo pin drop back to LOW. This is the most common failure mode for 5V sensors on 3.3V microcontrollers. Here are the first three things to check, ranked by probability:

1. Voltage Divider Integrity (Most Likely): The Echo pin is outputting 5V. If your 2kΩ pull-down resistor is missing, loose, or the wrong value, the 5V signal will backfeed into GPIO 27, triggering the ESP32's internal protection diodes and holding the pin HIGH. Disconnect the Echo wire, power the ESP32, and measure the voltage at the junction of the 1kΩ and 2kΩ resistors while the sensor is pinging. It must read between 3.2V and 3.4V.
2. 5V Rail Sag: The HC-SR04 draws a spike of current when the ultrasonic transducers fire. If you are powering the ESP32 from a weak PC USB port (limited to 500mA), the 5V VIN rail will sag below 4.5V, causing the sensor's internal comparator to lock up. Use a dedicated 5V 2A wall adapter.
3. Acoustic Multipath Reflection: If the sensor is mounted near metallic EMT conduit or a wire gutter, the 15-degree ultrasonic cone might be bouncing off the pipe and returning a chaotic, stretched echo that exceeds the timeout window. Cup your hand around the sensor to narrow the beam; if the error stops, you need to 3D-print a shroud for the transducers.

Extending and Simplifying the Build

Depending on your deployment environment, you may want to modify this base design.

• How to Extend (Home Assistant Integration): To log code violations over time, add the PubSubClient library and configure the ESP32 to publish the distance_in float to an MQTT broker (e.g., Mosquitto) on topic home/sensors/panel_clearance. You can then create an automation in Home Assistant that sends a push notification to your phone if the distance drops below 36 inches for more than 5 minutes.
• How to Simplify (Headless Mode): If the panel is in a dark, finished utility closet where an OLED display is useless, strip out the Wire.h and Adafruit_SSD1306 libraries. Rely entirely on the Serial output or add a simple 5mm Red LED to GPIO 26 that illuminates when the distance_cm < CLEARANCE_THRESHOLD_CM condition is met. This reduces power draw and frees up I2C pins for other sensors.
