For a standard 30A 240V circuit, use 10 AWG copper wire on a 30A double-pole breaker. For a 50A 240V circuit, use 6 AWG copper on a 50A breaker. These sizes assume copper conductors, 75°C terminations, and 30°C ambient temperature.
Baseline Assumptions for this Guide: All default sizing below assumes copper conductors, 75°C terminal ratings (standard for modern breakers and receptacles), 30°C (86°F) ambient temperature, and a maximum of three current-carrying conductors in a raceway. If your setup deviates, consult the derating sections below.

The Baseline Sizing Rules for 240V Circuits

Sizing wire for 240V circuits follows the exact same National Electrical Code (NEC) ampacity rules as 120V circuits, but the physical wiring topology differs. A pure 240V load (like a baseboard heater or a dedicated EV charger) requires two hot legs and a ground, but no neutral. A 120/240V appliance (like an electric range or dryer) requires two hots, a neutral, and a ground. In both cases, the wire gauge is dictated by the maximum current draw and the overcurrent protective device (the breaker).

Under NEC Article 240.4, conductors must be protected against overcurrent in accordance with their ampacities. You cannot simply match a wire to a breaker based on guesswork; you must use the NEC ampacity tables and apply correction factors. The most common mistake DIYers make is sizing the wire for the 90°C column because they bought THHN wire, only to fail inspection because the breaker lugs are only rated for 75°C.

For a definitive reference on standard breaker sizing and conductor protection, the NFPA 70 (NEC) standard development documentation outlines the strict hierarchy of terminal temperature ratings over insulation temperature ratings.

Ampacity Tables and the 75°C Terminal Rule

To understand why we pick specific gauges, you have to look at NEC Table 310.16 and NEC 110.14(C). Even if your wire insulation is rated for 90°C (like standard THHN/THWN-2), you must size the circuit based on the 75°C column unless the equipment is explicitly listed and marked for 90°C terminations. Almost no residential breakers or receptacles are rated for 90°C terminations.

NEC Table 310.16 Excerpt: Copper Conductors, Not More Than 3 Current-Carrying
AWG Size 60°C Column (NM-B / Romex) 75°C Column (THHN in Conduit) Max Standard Breaker
12 AWG 20A 25A 20A
10 AWG 30A 35A 30A
8 AWG 40A 50A 40A / 50A*
6 AWG 55A 65A 60A
4 AWG 70A 85A 80A

*Note: 8 AWG at 75°C is rated 50A, but 50A breakers are often paired with 6 AWG for continuous loads to satisfy the 125% rule.

Why this size and not one smaller? Consider a 40A 240V circuit. You might wonder why you can't use 10 AWG copper. In the 75°C column, 10 AWG is only rated for 35A. Putting a 40A breaker on 35A wire means the breaker will not trip before the wire overheats, violating NEC 240.4. You must step up to 8 AWG (rated 50A at 75°C) and protect it with a 40A breaker.

Voltage Drop: When Distance Forces a Size Up

Ampacity tables assume the wire can handle the heat, but they do not account for voltage drop over distance. NEC 210.19(A) Informational Note recommends keeping branch circuit voltage drop under 3% for reasonable efficiency. On a 240V circuit, 3% equals 7.2 volts.

Let's run a voltage drop check for a 50A, 240V circuit using 6 AWG copper wire at a distance of 100 feet. Using the standard single-phase voltage drop formula: VD = (2 × K × I × D) / CM

  • K (Copper resistivity) = 12.9
  • I (Current) = 50A
  • D (One-way distance) = 100 ft
  • CM (Circular mils for 6 AWG) = 26,240

Calculation: (2 × 12.9 × 50 × 100) / 26,240 = 4.91V drop.
Percentage: 4.91V / 240V = 2.04%.
This is well under the 3% limit, so 6 AWG is perfectly safe at 100 feet.

What changes the answer? If that same 50A circuit needs to run 150 feet to a detached garage, the voltage drop on 6 AWG jumps to 7.37V (3.07%). You have now exceeded the 3% recommendation. To fix this, you must bump the wire size to 4 AWG copper, which drops the loss to 1.9% at 150 feet. The Southwire Voltage Drop Calculator is an excellent field tool for verifying these numbers before pulling wire.

Decision Matrix: Picking Your Exact Wire and Breaker

Use this decision tree to lock in your exact materials. This matrix terminates in concrete part recommendations based on standard residential installations.

Load Type / Amps Distance Installation Method Wire Pick (AWG & Type) Breaker Pick Concrete Part Example
30A (Dryer / Water Heater) < 75 ft Inside walls (NM-B) 10/2 NM-B with Ground 30A 2-Pole Southwire 10/2 NM-B (Cerrowire)
40A (EV Charger / Cooktop) < 50 ft Conduit (THHN) 8 AWG THHN (2 Hots, 1 Grn) 40A 2-Pole Cerro Wire 8 AWG THHN
50A (Welder / Range / EV) < 100 ft Inside walls (NM-B) 6/2 NM-B with Ground 50A 2-Pole Southwire 6/2 NM-B (Cerrowire)
50A (Welder / Range / EV) 100 - 150 ft Conduit (THHN) 4 AWG THHN (2 Hots, 1 Grn) 50A 2-Pole Southwire 4 AWG THHN

For the vast majority of standard 50A 240V residential runs under 100 feet, your default, no-fail pick is 6/2 NM-B copper cable on a 50A double-pole breaker.

Edge Cases: Aluminum, Bundling, and AHJ Inspections

While copper is the default for branch circuits, real-world constraints sometimes force deviations. Here is how to handle the variables that change the baseline answer.

Switching to Aluminum Conductors

Aluminum is cheaper and lighter, but it has lower conductivity and expands more under heat. You cannot use the same AWG for aluminum as you do for copper. For a 50A circuit, while 6 AWG copper is sufficient, you must step up to 4 AWG aluminum (rated 55A at 75°C). Furthermore, aluminum must only be terminated in lugs explicitly marked "AL" or "AL/CU", and you must apply an anti-oxidant compound like Noalox to prevent galvanic corrosion and high-resistance heating. Never mix copper and aluminum wire directly without a properly rated mechanical splice.

Conductor Bundling and Derating

If you pull more than three current-carrying conductors through a single conduit (for example, running two separate 240V circuits in one EMT pipe), the wires heat each other up. NEC 310.15(C)(1) requires you to derate the ampacity. If you have 4 to 6 current-carrying conductors, you must multiply the 90°C ampacity by 80%. This derating frequently forces you to jump up one or two wire sizes just to maintain your target breaker rating.

When to Call an Engineer or the AHJ

This guide covers standard branch circuits. You must pull a permit and have your local Authority Having Jurisdiction (AHJ) or a licensed electrical engineer confirm your design if:

  • You are sizing service entrance conductors (the main feed from the utility meter to your main panel).
  • Your calculated load exceeds 400A, requiring parallel conductor runs.
  • You are designing a complex commercial setup with continuous loads exceeding 80% of the breaker rating where ambient temperatures exceed 30°C (86°F), requiring compound derating calculations.
The Final Verdict: Stop guessing. For a standard 50A 240V circuit under 100 feet, buy 6 AWG copper (6/2 NM-B for in-wall, or individual 6 AWG THHN for conduit) and a 50A double-pole breaker. If your run exceeds 100 feet, bump to 4 AWG copper to beat voltage drop. Size the wire to the 75°C column, torque your lugs to the manufacturer's inch-pound specs, and your installation will pass inspection and run safely for decades.
