The standard colour code for a 100k (100,000 ohm) resistor is Brown, Black, Yellow (followed by a Gold or Silver tolerance band) for standard 4-band carbon or metal film resistors. For precision 5-band resistors, the code is Brown, Black, Black, Orange (followed by a Brown or Red tolerance band).
The 100k Resistor Colour Code Reference Table
Resistor color bands are read from left to right, ending with the tolerance band (which is typically spaced wider apart or colored Gold/Silver). Below is the exact breakdown for both standard and precision 100k resistors according to international standards.
| Band Position | 4-Band 100k (Standard) | 5-Band 100k (Precision) | Meaning / Multiplier |
|---|---|---|---|
| Band 1 (1st Digit) | Brown (1) | Brown (1) | First significant digit |
| Band 2 (2nd Digit) | Black (0) | Black (0) | Second significant digit |
| Band 3 (3rd Digit / Multiplier) | Yellow (x10,000) | Black (0) | 3rd digit (5-band) or Multiplier (4-band) |
| Band 4 (Multiplier / Tolerance) | Gold (±5%) or Silver (±10%) | Orange (x1,000) | Multiplier (5-band) or Tolerance (4-band) |
| Band 5 (Tolerance / Temp Co) | N/A | Brown (±1%) or Red (±2%) | Tolerance (5-band) |
Calculation check: For the 4-band, 10 (Brown-Black) × 10,000 (Yellow) = 100,000Ω. For the 5-band, 100 (Brown-Black-Black) × 1,000 (Orange) = 100,000Ω.
Regional Standards and the "Rows People Get Wrong"
When dealing with electrical standards, regional variants like NEC (US wiring), IEC 60446 (EU wiring), and old UK (pre-2004 red/black mains) cause endless confusion on the jobsite. However, for passive components, the world is unified under IEC 60062. Older UK equipment (pre-1970s) sometimes followed BS 1852, which utilized identical band colors but occasionally paired them with alphanumeric body stamping (e.g., "100K J"). US military specs (MIL-PRF-55342) add a 6th band for failure rate (e.g., Yellow for 0.1% failure rate per 1,000 hours).
Despite global standardization, bench technicians consistently misread specific rows on the 100k resistor. Here are the most common pitfalls:
- The Multiplier Shift: In a 4-band 100k, the multiplier is Yellow ($10^4$). In a 5-band 100k, the multiplier is Orange ($10^3$). Swapping these mental models yields 1MΩ or 10kΩ, which will completely break a bias network.
- Red vs. Orange Fading: Cheap carbon film resistors baked at 85°C+ inside enclosed power supplies often have their Orange band fade to a muddy Red. A 100k 5-band (Brown-Black-Black-Orange) misread as Red becomes a 22k (Brown-Black-Black-Red) — a catastrophic difference in an op-amp feedback loop.
- Orientation Errors: Gold and Silver are never used as significant digits (Band 1 or 2). Always start reading from the end opposite the Gold/Silver band. If both ends look ambiguous, the tolerance band is usually physically wider or spaced further from the others.
Safe Interpretation When Markings Are Faded or Burnt
When a resistor has been subjected to thermal runaway or harsh flux chemicals, the paint bands will blister or turn entirely black. Do not attempt to scrape the paint off to "guess" the underlying color. Instead, rely on your digital multimeter (DMM), but you must follow proper isolation procedures.
Step 1: Isolate the Component
Measuring a resistor while it is still soldered into a circuit (in-circuit testing) will almost always yield a falsely low reading. This is because your DMM is measuring the 100k resistor in parallel with the rest of the circuit's impedance. According to the parallel resistance formula ($R_{total} = \frac{R_1 \times R_2}{R_1 + R_2}$), if your 100k resistor is in parallel with a 100k pull-down network, your meter will read 50kΩ.
Step 2: Lift One Leg
Desolder and lift at least one leg of the resistor off the PCB pad. This breaks the parallel circuit path.
Step 3: Measure and Account for Lead Resistance
Touch your DMM probes directly to the metal leads. For a 100k resistor, standard test lead resistance (typically 0.2Ω to 0.5Ω) is mathematically negligible. If your meter reads 98.5kΩ on a Gold-banded resistor, it is well within the ±5% tolerance (95kΩ to 105kΩ) and is perfectly safe to reuse. If it reads 120kΩ or "OL" (Open Loop), the internal resistive element has fractured from thermal stress and must be replaced.
